HVAC Condenser Fan Motor – EM3209F

EM3209F Condenser Fan Motor – 1/8 HP – 825 RPM – 460 Volt – HVAC Outdoor Condenser Replacement MotorRestore reliable cooling performance and condenser airflow with the EM3209F condenser fan motor. Designed for residential and light commercial HVAC systems, this high-performance PSC condenser fan motor is a direct OEM replacement for many outdoor condensing units and heat pump systems.The EM3209F features dependable 1/8 horsepower output, 825 RPM operation, and durable Totally Enclosed Air Over (TEAO) construction engineered to withstand demanding outdoor HVAC environments. Built with ball bearings and thermally protected operation, this motor delivers reliable long-lasting airflow performance for air conditioner condensers and heat pump systems.Key Features:• OEM Replacement Condenser Fan Motor – Designed for outdoor AC condenser and heat pump applications• 1/8 HP Performance – Provides dependable condenser airflow and cooling operation• 825 RPM Operation – Optimized for HVAC condenser fan applications• Totally Enclosed Air Over (TEAO) Design – Helps protect against moisture and outdoor contaminants• Reversible Rotation – Compatible with CW or CCW applications depending on wiring configuration• Permanent Split Capacitor (PSC) Design – Reliable and energy-efficient motor operation• Ball Bearing Construction – Smooth operation and extended motor life• Thermally Protected – Helps prevent overheating and extends motor life• Universal OEM Replacement – Compatible with many Carrier, Goodman, Rheem, Trane, Lennox, York, and aftermarket HVAC systemsSpecifications:• Model: EM3209F• Motor Type: Condenser Fan Motor• Horsepower: 1/8 HP• Voltage: 208-230V• Phase: Single Phase• Frequency: 60 Hz• RPM: 825• Speeds: Single Speed• Amperage: Approx. 1.1 Amps• Frame Size: 48Y Frame• Motor Diameter: 5.6″ / 5-5/8″• Rotation: Reversible• Shaft Diameter: 1/2″• Shaft Length: 6″• Shaft Style: Double Flat• Bearings: Ball Bearings• Enclosure: Totally Enclosed Air Over (TEAO)• Capacitor Required: 5 MFD / 370V• Thermal Protection: Automatic Overload• Mounting: Extended Studs / Belly Band Mount• Lead Length: Approx. 36″ Leads• Insulation Class: Class F• Ambient Rating: 70°C• Duty Cycle: Air Over / Continuous DutyReplaces OEM Part Numbers:Century / A.O. Smith• EM3209F• EM3209Packard• 43709Mars• 10709Diversitech / Wagner• WG840709Universal Cross References• SE3209F• SS3209• R3209Compatible HVAC Equipment Applications:• Outdoor Air Conditioner Condensing Units• Heat Pump Condenser Units• Residential Split Systems• Rooftop HVAC Units• Outdoor Fan Assemblies• Commercial HVAC Condensers• Refrigeration Condensing Units• Economaster Condensing UnitsImportant Fitment Notice:• Always verify horsepower, voltage, RPM, shaft dimensions, and rotation before ordering• Requires 5 MFD / 370V capacitor• Capacitor may not be included unless otherwise specified• Confirm shaft length and mounting configuration prior to installation• Professional HVAC installation recommended• Designed specifically for condenser fan applicationsWhy Replace Your Condenser Fan Motor?A failing condenser fan motor can cause overheating, poor cooling performance, compressor shutdowns, excessive energy consumption, and complete HVAC system failure. Replacing a worn condenser fan motor restores proper condenser airflow and helps maintain efficient cooling system performance.Why Choose the EM3209F Condenser Fan Motor?The EM3209F is a trusted universal condenser fan replacement motor designed for dependable HVAC performance. With durable TEAO construction, reversible rotation, dependable 825 RPM operation, and broad OEM compatibility, this motor is an excellent solution for restoring reliable condenser airflow and cooling performance in residential and light commercial HVAC systems.Nameplate SpecificationsPhase:1Output HP:1/3-1/8 HpOutput KW:0.25 kWVoltage:460 VSpeed:825 rpmService Factor:1Frame:48YEnclosure:Totally EnclosedThermal Protection:AutomaticAmbient Temperature:70 °CFrequency:60 HzCurrent:1.0 ADuty:Air OverInsulation Class:FUL:RecognizedCSA:YCE:NA2L Status:A2L CertifiedNumber of Speeds:1Technical SpecificationsElectrical Type:Permanent Split CapacitorStarting Method:Across The LinePoles:8Rotation:ReversibleMounting:Extended StudsMotor Orientation:AnyDrive End Bearing:BallOpp Drive End Bearing:BallFrame Material:Rolled SteelShaft Type:FlatOverall Length:11.80 inFrame Length:5.24 inShaft Diameter:0.500 inShaft Extension:6.0 inGeneral SpecificationsUPC:786674069887Weight:16.00 LBPackaged Length:13.78 INPackaged Width:6.41 INPackaged Height:6.81 INCountry of Origin:IndiaCompatible HVAC BrandsThe EM3209F is commonly used in equipment manufactured by:CarrierBryantPayneRheemRuudTraneAmerican StandardYorkColemanLuxaireLennoxArmstrong AirDucaneGoodmanAmanaHeilTempstarComfortmakerArcoaireDay & NightICP (International Comfort Products)NordyneInterthermFrigidaireMaytagAs with all condenser fan motors, compatibility should be verified by matching HP, voltage, RPM, frame size, shaft dimensions, capacitor rating, and mounting configuration.Compatible with many Carrier®, Bryant®, Payne®, Rheem®, Ruud®, Trane®, American Standard®, York®, Coleman®, Luxaire®, Lennox®, Armstrong Air®, Ducane®, Goodman®, Amana®, Heil®, Tempstar®, Comfortmaker®, Arcoaire®, Day & Night®, ICP®, Nordyne® and other air conditioning condenser and heat pump systems utilizing a 1/4 HP, 825 RPM, 208-230V, 48Y frame PSC condenser fan motor. Always verify horsepower, voltage, RPM, shaft dimensions, mounting style, capacitor size, and rotation before ordering.Replaces: Century EM3209F, Carrier HC39GE209, Rheem 51-23055-09, Trane MOT18909, York S1-02425890900, ICP 1162909, Nordyne 621909, Fasco D790, Mars 10209, Packard 43209, Rotom R43209, Wagner WG840209, Smart Electric SE3209.
