Blue Sea 5015 ST Glass Fuse Block wNegative Bus 5015

5015 ST Glass Fuse Block with Negative Bus

Features:

• Clear insulating cover with label recesses for accept Large Format Labels
• Cover insulates all conductive parts, satisfying ABYC/USCG requirements and storing spare fuses
• Tin-plated copper buses and Phosphor Bronze fuse clips give 30 Ampere rating per circuit
• Accepts AGC (Fast Acting), MDL (Time-Delay) and all other 3AG Glass Fuses

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Fuse Type: AGC/MDL
• Type: Fuse Blocks
• Box Dimensions: 2″H x 4″W x 8″L WT: 0.6 lbs
• UPC: 632085050153

Owner’s Manual (pdf)
