Airmar’s CAST App has new user-friendly benefits:
- Calibrate the DST810 in a simple, intuitive way regardless of the instrument brand or model that is on board
- Conduct basic and advanced heel-compensated speed calibrations for improved speed-through-water outputs across the speed range
- Advanced Speed Calibration allows for manual speed entries for multiple heel angles and up to 10 speeds, formerly only possible through expensive PC software
- Enable and disable PGN’s and set offset and output rates
The Perfect Sensor for Every Use
SAILING
- New 5 Hz speed output for visibly smoother speed data.
- Incredibly easy calibration via Airmar’s CAST App. Wirelessly connect, calibrate speed, and configure data.
- DST810 stores configurations and delivers data to the NMEA 2000® network.
- Depth, heel-corrected speed-through-water, heel and trim, and water temperature from one installed multisensor.
POWERBOATS
- 5 Hz speed, depth, pitch and roll, and water temperature from one installed instrument.
- Simple depth offsets and corrected speed-through-water via Airmar’s CAST™ App.
- Popular depth sensor for shallow water performance.
Specifications
- Weight:
- 0.9 kg (2.0 lb)—Plastic
- 1.6 kg (3.5 lb)—Bronze
- 1.9 kg (4.2 lb)—Stainless Steel
- Acoustic Window: Urethane
- Hull Deadrise: Up to 22°
- Data Update Rate:
- Depth: 1X/second
- Speed: 5X/second
- Heel/Trim: 10X/second
- Attitude Accuracy: +/– 1° nominal after sensor calibration
- Depth Frequency: 235 kHz
- Minimum Depth Range: 0.5 m (1.6′)
- Maximum Depth Range: Up to 100 m (330′)—NMEA 2000®
- Speed Range: Up to 45 knots
- Pressure Rating: 3 m (10′)
- Pulse Rate: 20,000 p/nm* (5.6 Hz per knot)—*p/nm = pulses per nautical mile
- Supply Voltage: 9 VDC to 16 VDC—per NMEA 2000
- Supply Current: <200 mA—per NMEA 2000®
- Wireless Protocol: Bluetooth Low Energy (BLE)
- Wireless Range: Up to 30 feet depending on mount location
- Standard Cable Length: 6 m (20′) DeviceNet—NMEA 2000®
- Temperature Sensor Accuracy: ±0.5°C (±1.8°F)
- Temperature Sensor Range: -10°C to 40°C (14°F to 104°F)
- NMEA 2000 Load Equivalency Number (LEN): 3
- CE Regulation: Complies to IERC60945
